RIVER XL2 | LLD Light

RIVER XL2

Recessed

RIVER XL2

18W

IP68IK09

drive

Compose the code

Supply	Led Color	Optics	Optics 2	Cable	Finishing	Dimmer	Cri	Filter
24Vdc	2200 K2700 K3000 K4000 KRedGreenBluRGBW	18° 24° 36° diffused asym 60° 20x50°		WP 3mWP 10mWP 15mNOWP RGBW 3m RGBW-3m only	Steel		>80	HC,BC,BD RGBW - HC only \| HC - 18°, 24°, 36°, 60°, 20x50°, ASYM only \| BC - 18°, 24°, 36°, 60° only \| BD - Diffused only

Technical features
Installation
Supply
Accessories
Download

Kg 2,4

Material:

AISI 316L Stainless steel body
AISI 316L stainless steel trim
Transparent tempered glass and PMMA lens

Connection:

24Vdc – Parallel

Installation:

Recessed on ground with housing box (not included)
Recessed on brickwork with housing box (not included)
Installation out of water with standard housing box
Permanent immersion installation with IP68 housing box

Controller

Phase cut dimmer

NOTE: For power supply options, please visit the Power Supplies section of this site.

Accessories needed for installation:

CA101 - Housing box
C8101 - Housing box
HC - The honeycomb filter is an anti-glare filter and must be ordered contextually to the lighting fixture
BC - The Black & Clear filter, an anti-glare screen half black screen-printed and half transparent, must be ordered contextually to the lighting fixture
BD - The Black & Diffused filter, an anti-glare and semi-diffusing screen half black and half screen-printed diffusing, must be ordered contextually to the lighting fixture

NOTE:

Documents available for download:

DATA SHEET
